Products Size:(L*W*Hmm) 920×400×720

Motor Type  :brushed DC , 250W/24V

Motor Max Loaded Amps :17.8A

Torque :1.21(N.m)

Max RPM  : 2700±7.5%(rpm)

Controller Type : Air cooled, non water -proof; brake shutoff, charger port

Battery: Lead-Acid Battery,12V /7AH*2pcs

Charging Time :6-8 hours

Battery :Charger Input-100-240VAC,50/60HZ,1.8A Max; Output-DC 24V,1.5A

Special Features Dismountable :Handle bar

Turning Angle :32º

Transmission Ratio: 92/11

Seat Height : 340 mm

Wheel base Distance :635 mm

Front & Rear Tire and Rim :110/50-6.5

Maximum Carrying Capacity  :45kgs

Mini Ground Clearance :90 mm

Maximum Speed Low speed :11km/h ; high speed:21 km/h

Maximum Distance Range :13 km

Control System :handle bar control

Throttle Type: tum control

Front & Rear Braking System :Mechanical disc, left handle control

Drive System: Chian drive

Brake Distance ≤2m (11km/ h); ≤4m (21km/ h)

Packing Size(L*W*Hmm) :950×285×520

N.W/G.W :23kgs/26kgs

Container loading(20FT/40FT/40HQ): 192/392/490
