Products Size(L*W*Hmm) 1110×600×850

Motor Type :brushed DC , 350W/24V

Motor Max Loaded: Amps 26.4A

Torque :1.3(N.m)

Max RPM  : 2700±7.5%(rpm)

Controller Type : Air cooled, non water -proof; brake shutoff, charger port

Battery :Lead-Acid Battery,12V /10AH*2pcs

Charging Time :6-8 hours

Battery Charger :1-1.5amps(~10% of battery ah)-UL approved

Special Features: Folding Handle bar

Turning Angle :30º

Transmission Ratio :82/11

Seat Height  :290 mm

Wheel base Distance :770 mm

Front & Rear Tire and Rim :110/50-6.5

Maximum Carrying Capacity : 75kgs

Mini Ground Clearance ;90 mm

Maximum Speed ;25 km/h

Maximum Distance Range :20 km

Control System :handle bar control

Throttle Type :tum control

Front & Rear Braking System :Mechanical disc, left handle control

Drive System: Chian drive

Brake Distance :4m

Packing Size(L*W*Hmm) :1150×310×610

N.W/G.W :31kgs/36kgs

Container loading(20FT/40FT/40HQ): 105/223/300
